Dynamix UPS Replacement Battery 12V 9AH

RT 1290 is a general purpose battery with 5 years floating design life, meet with IEC, JIS standard .With heavy duty grid, thickness plates, special additives, RT series battery have long and reliable standby service life.

• Cells Per Unit: 6
• Voltage Per Unit: 12
• Capacity: 9.0Ah@20hr-rate to 1.75V per cell @25 C
• Weight: Approx. 2.55Kg
• Max. Discharge Current: 90 A (5 sec)
• Internal Resistance: Approx. 18m Ohm
• Operating Temperature Range: Discharge: -20 ~60C; Charge: 0 C~50 C; Storage: -20 C~60 C
• Normal Operating Temperature: 25 C±5 C
• Floating Charging Voltage: 13.7 to 13.9 VDC/unit Average at 25 C
• Recommended Maximum Charging Current Limit: 2.7 A
• Equalization and Cycle Service: 14.6 to 14.8 VDC/unit Average at 25 C
• Self Discharge: RITAR batteries can be stored for more than 6 months at 25 C. Self-discharge ratio less than 3% per month at 25 C. Please charge batteries before using
• Terminal: Faston tab 250(F2)
• Container Material: A.B.S. (UL94-HB)
• Dimensions (LxWxH): 151 x 65 x 100 mm
