Product Description:
Honeywell ScanPal EDA10A 10.1 Inch Qualcomm SM4350-AC 8GB RAM 128GB Flash Rugged Tablet - Wi-Fi Only
The Honeywell ScanPal EDA10A tablet is a rugged yet lightweight solution for mobile business users who need fast, reliable mobile data access on a high-resolution, 10-inch screen. Featuring Wi-Fi 6 communications, the EDA10A provides high-speed connectivity indoors for users in retail and field service.
Features:
• Powerful hardware platform based on the Qualcomm Snapdragon 4350-AC, octa-core processor, 8 GB/ 128 GB memory to handle different workloads.
• Rugged and sleek EDA10A is designed to endure frequent drops and vibrations. Gorilla Glass 5 touchscreen, 1.3 m (4.3 ft) drop per MIL-STD810H standards, 2 m (6.6 ft) drop with protective boot, and IP65 rating against dust and water.
• Embedded with latest Wi-Fi 6 connectivity, the EDA10A increase data throughput and provides a better experience for voice or video communications even in a highly dense connected environment.
• Removable 8,000 mAh lithium-ion battery that can last for up to 12 hours or more of straight use without interruption. Hot-swap supported.
• Easily scan barcodes, even damaged ones, with the Honeywell enterprise level S0703 imager. Document images with the 16MP auto-focus camera and make video calls with the 8MP front camera.
• Rugged and sleek EDA10A is designed to endure frequent drops and vibrations. Gorilla Glass 5 touchscreen, 1.3 m (4.3 ft) drop per MIL-STD810H standards, 2 m (6.6 ft) drop with protective boot, and IP65 rating against dust and water.
• Embedded with latest Wi-Fi 6 connectivity, the EDA10A increase data throughput and provides a better experience for voice or video communications even in a highly dense connected environment.
• Removable 8,000 mAh lithium-ion battery that can last for up to 12 hours or more of straight use without interruption. Hot-swap supported.
• Easily scan barcodes, even damaged ones, with the Honeywell enterprise level S0703 imager. Document images with the 16MP auto-focus camera and make video calls with the 8MP front camera.
Specifications:
Mechanical:
• Display Size: Gorilla Glass 5, 25.7cm (10.1 in)
• Resolution: 1920 x 1200 Full High Definition, 550 nit brightness
• Backlight: LED
• Touchscreen: Multi-touch capacitive (CTP), GFF
• Hard Keys: 5 side keys for volume up/down, right/left scanning and power on/off, 1 touch key on bottom side for scanning
• Dimensions: 257 x 166.5 x 11.7 mm
• Weight: 674g
Environmental:
• Operating Temperature: -20°C to +50°C (-4°F to +122°F)
• Storage Temperature: -30°C to +70°C (-22°F to 158°F)
• Humidity: 5% to 95% (non-condensing)
• Drop: Multiple 1.3 m (4.3 ft) drop to concrete per MIL-STD-810H under room temperature. With optional protective boot, Multiple 2.0 m (6.6 ft) drop to concrete per MIL-STD-810H under room temperature
• Vibration: MIL-STD-810H, Method 514.6, Procedure I
• Environmental Sealing: IP65
• Electrostatic Discharge (ESD): ±8 kV direct; ±15 kV air
System Architecture:
• Processor: Qualcomm Snapdragon SM4350-AC, Octa-Core, up to 2.2GHz
• Memory: 8 GB RAM/128 GB Flash
• Operating System: Android 12, and upgradeable to Android 14
• Storage Expansion: MicroSD (standard supports up to 2 TB)
• Rear Camera: 16-megapixel color camera
• Front Camera: 8-megapixel color camera
• PC Interface: USB 3.0 with Type-C interface
• Interface Ports: 6 PIN bottom connection
• Battery: Li-Ion, 8,000 mAh, 3.85 V, removable, hot swappable
• Real-Time Clock (RTC): 5 min back up vie super-cap
• Charging Time: less than 5.5 hours with wall adapter (10W) and single charging dock in standby mode, 2.5 hours with QC/PD wall adapter
• Battery Runtime: more than 12 hours (Battery life depends on usage and other factors)
• Scan Engine: Honeywell S0703 Slim Imager (1D/2D barcode symbologies)
LED:
• Battery Status Indicator: red/green/blue
• Scan Indication: red/green
• Sensors: 3-axes accelerometer, 3-axes gyroscope sensor, compass, light sensor, and proximity sensor
Localization & Language: Worldwide English
Wireless Connectivity:
• WLAN (Wi-Fi Alliance certified): IEEE 802.11 a/b/g/n/ac/ax
• Additional WLAN Features: 802.11 d/e/h/i/k/r/v/w/mc, 2X2 MU-MIMO
• WLAN Security: OPEN, WEP, WPA/WPA2 (Personal and Enterprise WPA2), WPA3 (OWE, SAE, Enterprise)
• WLAN Supported EAP: TLS, PEAP, TTLS, PWD, LEAP, CCX compliant
• Bluetooth: Bluetooth Class 5.1/2.1 + EDR Class 2 (Bluetooth LE)
• NFC: Integrated Near Field Communication
• Display Size: Gorilla Glass 5, 25.7cm (10.1 in)
• Resolution: 1920 x 1200 Full High Definition, 550 nit brightness
• Backlight: LED
• Touchscreen: Multi-touch capacitive (CTP), GFF
• Hard Keys: 5 side keys for volume up/down, right/left scanning and power on/off, 1 touch key on bottom side for scanning
• Dimensions: 257 x 166.5 x 11.7 mm
• Weight: 674g
Environmental:
• Operating Temperature: -20°C to +50°C (-4°F to +122°F)
• Storage Temperature: -30°C to +70°C (-22°F to 158°F)
• Humidity: 5% to 95% (non-condensing)
• Drop: Multiple 1.3 m (4.3 ft) drop to concrete per MIL-STD-810H under room temperature. With optional protective boot, Multiple 2.0 m (6.6 ft) drop to concrete per MIL-STD-810H under room temperature
• Vibration: MIL-STD-810H, Method 514.6, Procedure I
• Environmental Sealing: IP65
• Electrostatic Discharge (ESD): ±8 kV direct; ±15 kV air
System Architecture:
• Processor: Qualcomm Snapdragon SM4350-AC, Octa-Core, up to 2.2GHz
• Memory: 8 GB RAM/128 GB Flash
• Operating System: Android 12, and upgradeable to Android 14
• Storage Expansion: MicroSD (standard supports up to 2 TB)
• Rear Camera: 16-megapixel color camera
• Front Camera: 8-megapixel color camera
• PC Interface: USB 3.0 with Type-C interface
• Interface Ports: 6 PIN bottom connection
• Battery: Li-Ion, 8,000 mAh, 3.85 V, removable, hot swappable
• Real-Time Clock (RTC): 5 min back up vie super-cap
• Charging Time: less than 5.5 hours with wall adapter (10W) and single charging dock in standby mode, 2.5 hours with QC/PD wall adapter
• Battery Runtime: more than 12 hours (Battery life depends on usage and other factors)
• Scan Engine: Honeywell S0703 Slim Imager (1D/2D barcode symbologies)
LED:
• Battery Status Indicator: red/green/blue
• Scan Indication: red/green
• Sensors: 3-axes accelerometer, 3-axes gyroscope sensor, compass, light sensor, and proximity sensor
Localization & Language: Worldwide English
Wireless Connectivity:
• WLAN (Wi-Fi Alliance certified): IEEE 802.11 a/b/g/n/ac/ax
• Additional WLAN Features: 802.11 d/e/h/i/k/r/v/w/mc, 2X2 MU-MIMO
• WLAN Security: OPEN, WEP, WPA/WPA2 (Personal and Enterprise WPA2), WPA3 (OWE, SAE, Enterprise)
• WLAN Supported EAP: TLS, PEAP, TTLS, PWD, LEAP, CCX compliant
• Bluetooth: Bluetooth Class 5.1/2.1 + EDR Class 2 (Bluetooth LE)
• NFC: Integrated Near Field Communication
Package Contents:
• EDA10A terminal
• Battery
• USB cable
• Battery
• USB cable
Due to the specialised nature of Point of Sale items this product cannot be exchanged or returned (unless faulty). Please verify compatibility before purchase & if you have any questions, please contact us. We will be processing and shipping orders during the holiday period, however our services may be impacted due to the closure of some of our supplier warehouses. Full operations will resume on Monday 6th January. For the fastest response to your queries please email us at sales@elive.co.nz
Additional Details:
-
Stock Availability: Out of Stock!
-
Warranty: 1 Year
-
Manufacturer: Honeywell Shop
-
Product Found In: Point of Sale Terminals
-
Model Number: EDA10A-00BE91N21RK
-
Part Number: DD012275
